AZPTGear Pump nta:
| Optimized siab pulsation, txo cov suab nrov emissions thiab oscillations nyob rau hauv lub system |  |
| Kev ua tau zoo zoo ib yam vim yog siab - ntim ntau lawm | |
| Lub neej ua haujlwm ntev | |
| Swb bearings rau siab loading | |
| Tsav shafts ua raws li ISO lossis SAE thiab cov kev daws teeb meem tshwj xeeb | |
| Kev sib txuas ntawm chaw nres nkoj: Kev sib txuas flanges lossis ntsia hlau-hauv xov | |
| Kev sib xyaw ntawm ntau lub twj tso kua mis tuaj yeem ua tau | |
| Muaj ntau yam configuration variants muaj |
AZPT series iav twj tso kua mis technical parameters:
Hais txog peb:
Ningbo Linuo Hydraulic Technology Co., Ltd. Muaj cov kws tshaj lij R & D pab neeg, cov cuab yeej tsim khoom thiab kev sim siab, siab - cov neeg ua haujlwm zoo thiab nruj ISO9001 kev tswj hwm zoo, tib lub sijhawm muaj ntau daim ntawv pov thawj, EU CE daim ntawv pov thawj. Lub tuam txhab txuas ntxiv tsim kho tshiab thiab txhim kho, kev tshawb fawb thiab kev tswj xyuas zoo, kom ntseeg tau tias kev txhim kho tsis tu ncua ntawm cov khoom zoo. Txhawm rau kom ntseeg tau qhov kev ntseeg siab ntawm cov khoom siv hydraulic thiab txo qis qhov tsis ua haujlwm ntawm cov khoom, peb tswj txhua qhov txuas nruab nrab ntawm kev tsim - ntau lawm - kev sim - kev thauj mus los thiab ua ntau yam kev sim ntawm cov khoom tsim tshiab los xyuas qhov kev ua tau zoo ntawm cov khoom, thiab thaum kawg ua kom cov khoom zoo.
AZPTPumping txoj cai:
Lub geometry ntawm kev hloov chaw gearing, sib npaug hauv daim ntawv los ntawm kev sib hloov ntawm lub tog raj kheej, ua rau cov yam ntxwv ntawm parabolic txaus qhia ntawm no ntawm nplooj ntawv tom ntej. Nyob rau hauv lub twj tso kua mis txheem, tus yam ntxwv no yog rov qab txhua zaus ib tug iav meshes. Nrog lawv ob lub-flank system, qhov ntws tawm ntawm SILENCE cov twj tso kua mis raug txo los ntawm 75% - nrog rau kev sib tw qis qis ntawm cov khoom siv hauv qab dej - ntawm ob npaug ntawm qhov tseem ceeb zaus. Thaum lub sij hawm tus txheej txheem no, cov iav khub muaj ib tug heev txo rear flank backlash, thiaj li hais tias hydraulic sealing yog muab tsis tau tsuas yog los ntawm lub pem hauv ntej flank ntawm lub iav tsav, tab sis kuj los ntawm lub rear flanks. Nyob rau hauv txoj kev no, sab pem hauv ntej thiab nram qab flanks alternately pab txhawb kev khiav tawm. Thiab los ntawm kev hloov kho cov duab ntawm cov metering notches, kev nthuav dav ntawm txoj kab hydraulic ntawm kev ua haujlwm yog ib nrab ntawm cov twj tso kua mis txheem.
Dab tsi yog qhov ua rau hnav ntawm lub log twj tso kua mis?
1, qhov laj thawj tseem ceeb yog qhov cuam tshuam rau qhov hnav ntau dhau. Iav twj tso kua mis hnav feem ntau suav nrog tsav ncej thiab bushing, passive gear center qhov thiab ncej tus pin, twj plhaub kab noj hniav thiab iav, iav kawg lub ntsej muag thiab lub twj tso kua mis cover. Thaum cov kev qhia tseem ceeb ntawm cov roj lubricating twj tso kua mis tsis ua tau raws li qhov yuav tsum tau ua tom qab hnav, nws yuav tsum tau disassembled thiab decomposed, nrhiav seb qhov hnav thiab degree, thiab siv cov kev ntsuas tsim nyog los kho.
Kev kho qhov hnav ntawm lub active ncej bushing qhov thiab lub qhov tsav lub tog raj kheej: Tom qab lub active ncej bushing qhov yog hnav, hnav cov cim yuav raug tshem tawm los ntawm txoj kev reaming, thiab ces lub bushing yog loj mus rau qhov sib thooj loj. Lub qhov tsav lub qhov hnav kuj raug tshem tawm los ntawm txoj kev hinged, thiab tom qab ntawd cov ncej tsav tau npaj raws li qhov loj ntawm lub qhov hinged.
2, Rexroth iav twj tso kua mis tsav ncej thiab bushing hnav, qhov sib txawv nce, yuav cuam tshuam rau cov roj twj tso kua mis. Hauv qhov no, qhov sib txawv ntawm qhov qub tuaj yeem rov qab los ntawm kev kho tus tsav ncej lossis bushing. Yog hais tias tus tsav ncej yog me ntsis hnav, tsuas yog nias tawm lub qub bushing thiab hloov nws nrog tus qauv loj bushing, thiab qhov sib txuam sib txawv tuaj yeem rov qab mus rau qhov kev tso cai.
3, Rexroth iav roj twj tso kua mis lub plhaub sab hauv kho kab noj hniav: lub twj tso kua mis sab hauv kab noj hniav hnav, feem ntau siv cov kab noj hniav sab hauv kho, uas yog, cov kab noj hniav sab hauv yog lined nrog cam khwb cia hlau lossis steel bushing. Tom qab ntxig lub casing, lub puab kab noj hniav yog lined mus rau qhov yuav tsum tau loj, thiab lub bushing ntawm lub protruding kawg lub ntsej muag yog hauv av kom nws yog flush nrog lub twj tso kua mis vaj tse nyob rau saum npoo.
